| Process: | Casting | Coating: | None |
|---|---|---|---|
| Dimension: | Custom Upon Request | Material: | Aluminum, Nickel, Cobalt |
Block Sinter Alnico LNG40 Permanent Magnets Guitar Pickup High Temperature Resistance
Description :
The casting process allows for the magnet to be manufactured into intricate and complex shapes, which are not possible with other magnetic materials.
Attributes of Cast Alnico
• Very temperature stable, great for high heat applications
• Working temperature can reach 550-600 °C
• Does not lend itself to conventional machining (hard and brittle)
• High residual induction and energy product compared to ceramic material
• Low coercive force compared to ceramic and rare earth materials (more subject to demagnetization)
Applications of Cast Alnico
Electricity Meters
Water Meters
Motorcycle odometers
| Physical Properties of Cast Alnico | |
| Curie Temperature (℃) | 760-890 |
| Max. Operating Temperature (℃) | 450-550 |
| Resistivity (μohm.cm) | 47-54 |
| Hardness (Hv) | 520-630 |
| Density (g/cm³) | 6.90-7.30 |
| Relative Recoil Permeability (μrec) | 1.70-4.70 |
| Saturation Field Strength (kOe,kA/m) | 2.7-6.3/215-500 |
| Temperature Coefficient of Br (%/℃) | -0.025 ~ -0.02 |
| Temperature Coefficient of iHc (%/℃) | +0.01 ~ +0.03 |
| ade | Br | HcJ | (BH)max | D | Equivalent< br> MMPA Class | % Change Per C | Tc< /div> | Tw | ||||
| mT | Gs | KA/m | Oe | KJ/m3 | MGOe | g/cm3 | Near Br | Near HcJ | ℃ | ℃ | ||
| *LN9 | 680 | 6800 | 30 | 380 | 9 | 1.13 | 6.9 | Alnico 3 | -0.03 | -0.02 | 810 | 450 |
| *LN10 | 600 | 6000 | 40 | 500 | 10 | 1.2 | 6.9 | -0.03 | -0.02 | 810 | 450 | |
| *LNG12 | 720 | 7200 | 45 | 500 | 12.4 | 1.55 | 7 | Alnico 2 | -0.03 | -0.02 | 810 | 450 |
| *LNG13 | 700 | 7000 | 48 | 600 | 12.8 | 1.6 | 7 | |||||
| LNG37 | 1200 | 12000 | 48 | 600 | 37 | 4.65 | 7.3 | Alnico 5 | -0.02 | 0.03 | 860 | 525 |
| LNG40 | 1250 | 12500 | 48 | 600 | 40 | 5 | 7.3 | |||||
| LNG44 | 1250 | 12500 | 52 | 650 | 44 | 5.5 | 7.3 | |||||
| LNG52 | 1300 | 13000 | 56 | 700 | 52 | 6.5 | 7.3 | Alnico 5DG | ||||
| LNG60 | 1350 | 13500 | 59 | 740 | 60 | 7.5 | 7.3 | Alnico 5-7 | ||||
| LNGT28 | 1000 | 10000 | 58 | 720 | 28 | 3.5 | 7.3 | Alnico 6 | -0.02 | 0.03 | 860 | 525 |
| LNGT36J< /div> | 700 | 7000 | 140 | 1750 | 36 | 4.5 | 7.3 | Alnico 8HC | -0.025 | 0.02 | 860 | 550 |
| *LNGT18< /div> | 580 | 5800 | 100 | 1250 | 18 | 2.2 | 7.3 | Alnico 8 | -0.025 | 0.02 | 860 | 550 |
| LNGT32 | 800 | 8000 | 100 | 1250 | 32 | 4 | 7.3 | Alnico 8 | -0.025 | 0.02 | 860 | 550 |
| LNGT40 | 800 | 8000 | 110 | 1380 | 40 | 5 | 7.3 | |||||
| LNGT60 | 900 | 9000 | 110 | 1380 | 60 | 7.5 | 7.3 | Alnico 9 | -0.025 | 0.02 | 860 | 550 |
