LNG44 Grade Cylinder Permanent Alnico Permanent Magnets Rod Used for Electronic Products

Large Image : LNG44 Grade Cylinder Permanent Alnico Permanent Magnets Rod Used for Electronic Products

Product Details:

Place of Origin:	CN
Certification:	ISO9001
Model Number:	YS-Alnico-20

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	Negotiation
Packaging Details:	Export packing, cartons, pallets
Delivery Time:	15~20 days
Payment Terms:	T/T, L/C
Supply Ability:	500Ton/year

Detailed Product Description

Shape:	Rod	Surface:	No Coating
Size:	Customized Upon Design	Working Temp.:	450~550 °C
Export:	Xiamen Port	Density:	7.3 G/cm3

Cylinder Alnico Rod Magnets LNG44 Grade Used for Electronic Products

Rod Alnico Magnets are made primarily from aluminum, nickel, cobalt, copper, iron and sometimes titanium. There are cast or sintered Alnico magnet due to different process craft .The common grade is AlNiCo 5 and AlNiCo 8.

The Advange of Cast Alnico magnet: They have stable temperature coefficient and great for heat applications. The working temperature can reach 550-600 °C.

The Shortage: But they are hard and brittle, not easily to conventional machining.

Magnetic Property for Cast Alnico Magnet

Grade	Br		HcJ		(BH)max		D	Equivalent< br> MMPA Class	% Change Per C		Tc	Tw
Grade	mT	Gs	KA/m	Oe	KJ/m3	MGOe	g/cm3	Equivalent< br> MMPA Class	Near Br	Near HcJ	℃	℃
LN9	680	6800	30	380	9	1.13	6.9	Alnico 3	-0.03	-0.02	810	450
LN10	600	6000	40	500	10	1.2	6.9	Alnico 3	-0.03	-0.02	810	450
LNG37	1200	12000	48	600	37	4.65	7.3	Alnico 5	-0.02	0.03	860	525
LNG40	1250	12500	48	600	40	5	7.3
LNG44	1250	12500	52	650	44	5.5	7.3
LNG52	1300	13000	56	700	52	6.5	7.3	Alnico 5DG
LNG60	1350	13500	59	740	60	7.5	7.3	Alnico 5-7
LNGT28	1000	10000	58	720	28	3.5	7.3	Alnico 6	-0.02	0.03	860	525
LNGT36J	700	7000	140	1750	36	4.5	7.3	Alnico 8HC	-0.025	0.02	860	550
LNGT18	580	5800	100	1250	18	2.2	7.3	Alnico 8	-0.025	0.02	860	550
LNGT32	800	8000	100	1250	32	4	7.3	Alnico 8	-0.025	0.02	860	550
LNGT40	800	8000	110	1380	40	5	7.3	Alnico 8	-0.025	0.02	860	550
LNGT60	900	9000	110	1380	60	7.5	7.3	Alnico 9	-0.025	0.02	860	550

Attributes of Alnico

Very temperature stable, great for high heat applications
Working temperature can reach 550-600 °C
Does not lend itself to conventional machining (hard and brittle)
High residual induction and energy product compared to ceramic material
Low coercive force compared to ceramic and rare earth materials (more subject to demagnetization)

Applications of Alnico Magnets

Electron tubes
Traveling wave tubes
Radar
Clutches and bearings
Motors
Relays
Controls
Generators
Receivers
Telephones
Microphones
Bell ringers

LNG44 Grade Cylinder Permanent Alnico Permanent Magnets Rod Used for Electronic Products

Tag:

alnico horseshoe magnet,

alnico round magnet
