Block Square RARE Earth Neodymium Block Magnets 10 X 5 X 3mm For Separator

Good quality NdFeB Permanent Magnets for sales
Good quality NdFeB Permanent Magnets for sales
I am glad to confirm that we received the whole purchase magnet on the scheduled time. As you promised all your products have a very high quality.

—— Mr. Roberto

The magnets have arrived, I thank you for the rapid dispatch. The quality of the magnets are great on the ones that have been inspected and tested.

—— Mr. David

We are well satisfied with your products.We have produced our product  using the magnets we purchased from you.. So far ,everything goes well.

—— Huseyin

I'm Online Chat Now

Block Square RARE Earth Neodymium Block Magnets 10 X 5 X 3mm For Separator

China Block Square RARE Earth Neodymium Block Magnets 10 X 5 X 3mm For Separator supplier
Block Square RARE Earth Neodymium Block Magnets 10 X 5 X 3mm For Separator supplier Block Square RARE Earth Neodymium Block Magnets 10 X 5 X 3mm For Separator supplier

Large Image :  Block Square RARE Earth Neodymium Block Magnets 10 X 5 X 3mm For Separator

Product Details:

Place of Origin: CN
Certification: ISO9001
Model Number: YSNEO-586

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Price: Negotiated
Packaging Details: Standard sea or air packing, such as cartons, wooden Case etc.
Delivery Time: 15~20 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500Ton per Year
Detailed Product Description
Material: Neodymium, Iron, Boron And A Few Transition Metals Grade: N38sh
Coating: NICuNi Max. Working Temp.: 150 Celsius Degree
Density: 7.4 G/cm3 Size: Length 100mm



Super Strong Block Square RARE Earth Neodymium Magnets 10 X 5 X 3mm For Separator



The NdFeB magnet are composed of Neodymium,iron, boron and a few transition metals. We express it: RE2TM14B(RE=Nd,Pr,Dy TM=Fe,Co).

The base compound of NdFeB magnet is Nd2Fe14B. Its molecular formula is similar to Nd2Fe14B’s. But if distribute totally based on the Nd2Fe14B, the magnetic property is low, even no magnetic field. In fact, the only difference is more Neodymium and boron. Only in this way, we can produce the permanent magnet.



Their max energy product can be 35MGOe~50MGOe , Neodymium magnets are developed rapidly and applied widely due to their perfect characteristic, rich raw material resource and reasonable price.



Attributes of Neodymium Material

  • Very high resistance to demagnetization
  • High energy for size
  • Good in ambient temperature
  • Moderately priced
  • Material is corrosive and should be coated for long term maximum energy output
  • Low working temperature for heat applications, but higher levels of heat resistance materials are being introduced periodically



Grade Br mt(KG) Hcb Koe(KA/m) iHc Koe(KA/m) (BH)max TW℃
        KJ/m3 (MGOe)
N42 1280-1320(12.8-13.2) ≧11.6(≧923) ≧12(≧955) 318-342(40-43) 80
N45 1320-1380(13.2-13.8) ≧11.0(≧876) ≧12(≧955) 342-366(43-46) 80
N48 1380-1420(13.8-14.2) ≧10.5(≧835) ≧12(≧955) 366-390(46-49) 80
N50 1380-1450(13.8-14.5) ≧10.5(≧835) ≧12(≧955) 474-406(47-51) 80

Magnetized Orientation



Block Square RARE Earth Neodymium Block Magnets 10 X 5 X 3mm For Separator
