Product Details:
Payment & Shipping Terms:
|
Shape: | Ring Shape | Material: | NdFeB |
---|---|---|---|
Coating: | Zinc Coated | Max. Working Temp.: | 80 Celsius Degree |
Tolerance: | +/-0.05mm | Size: | Customized Upon Request |
NdFeB magnets have the character of hardness and brittleness. After the magnetization, it’s magnetic attraction is big as 60times as the its own weight. So the Neodymium magnet must be picked up carefully and gently during assemble process and kept away from iron ware to avoid mutually attracting, causing chips and cracks or other damage to the magnet. For the bigger size, the personal safety and self-protection are more important. it’ll hurt operators in case that two strongly magnetized slices firmly attract unexpectedly. You can use machine equipments just like bolt or stick craft to assembly and fasten them.
Material | Neodyium, Iron, Boron |
Grade | N50 |
Shape | Ring |
Plating | Zinc Plated |
Magnetized | Axial or Diametrical |
Density | 7.4 g/cm3 |
Grade | Br mt(KG) | Hcb Koe(KA/m) | iHc Koe(KA/m) | (BH)max | TW℃ |
KJ/m3 (MGOe) | |||||
N50 | 1380-1450(13.8-14.5) | ≧10.5(≧835) | ≧12(≧955) | 474-406(47-51) | 80 |
Usage and Packing details:
